HLG Automatic Corrugated Laminating Machine

Scope Of Application：

The High-precision Full-Automatic Laminating machine is used for laminating thin paper,paperboard, grey board and coated paper, etc. It can meet the special processing requirements of double-sided printing and lamination of thin paper and thick paper. High laminating accuracy, no deformation before and after lamination. It is suitable for the processing of wine box, shoe box, tag, elevator, toy, gift box and exquisite packaging products, with high flatness, high precision and good hardness.

Performance Feature :

◆ Originality Paper dynamic calibration synchronization system

◆ Double-notch E-shaped design allows the laminated paper to be pushed in with a trolley.

◆ Front suction top feed paper feeding system, size changeover without adjustment, easy to operate

◆ The shake loose type take-up system can shake loose the overlapping products and then push them to ensure a neat and smooth take-up.

◆ The rotation speed and pressing length are electrically adjusted for convenient conversion

◆ PLC computer control system can automatically detect operation conditions,abnormal conditions, maintenance conditions and work records

◆ High precision coating system, automatic liquid level control, can accurately adjust the coating amount according to the paper demand to ensure uniform gluing.

Model	HLG-1480G
Max.sheet(wxl)	1450*1450mm
Min.sheet(wxl)	450*350mm
Thickness of upper paper	150-600g/㎡
Thickness of bottom paper	≤10mmA-F corrugated cardboard，＜300g cardboard
Machine speed	12000P/H
Accuracy	±1mm
Machine space	15700220260cm
Weights	7000kg
Power	22kw/380v

Samples :

Model	HLG-1680G
Max.sheet(wxl)	1650*1650mm
Min.sheet(wxl)	450*350mm
Thickness of upper paper	150-600g/㎡
Thickness of bottom paper	≤10mmA-F corrugated cardboard，＜300g cardboard
Machine speed	12000P/H
Accuracy	±1mm
Machine space	16100240260cm
Weights	7800kg
Power	26kw/380v

Samples :

Q1: Do you have different models for each machine?
Reply: Yes, we have different models and we can make the machine according to your requirements.

Q2: What is the production time?
Reply: Normally we need around 45 days.

Q3: What service you can offer after we buy the machine?
Reply: We have a few experienced technicians who can help to install and test running the machine anytime overseas. Moreover, our own export personel
will give you the service support after buying the machine. As long as you have any questions, we will try our best to help you.

Q4: What about the payment terms?
Reply: We accept T/T. 30% as deposit and 70% balance should be paid before delivery. We can also accept 100% confirmed irrevocable L/C at sight.
