Our special design for PP and PS PVC Film. This machine is suitable for any of thermoforms plastic sheet. This Plastic Thermoforming Machine is update according to the mostly development technical, compare with the traditional machine, It can solved many impossible commitment
This Plastic Thermoforming Machine forming and cutting neat and Clear. Cutting Off the product in order. Also good use for PP PS, PET,PVC etc.
| Model No. | NUD 550 |
| Cutting cycle | 10-24punch/min |
| Raw Material | PP/PS/PET/PVC/PLA |
| Forming area | 50*350*80mm |
| Heating Power | 65KW |
| Total Power | 380V 50HZ 80KW |
| Water Consumption | 0.3m³/h (Tap water or recycle water) |
| Air Pressure | 0.5-0.8(mpa) |
| Pressure of water supply | 0.2MPa |
| Dimensions （L×W×H） | 5950*1725*1900mm |
| Area occupied | 8700*3600 |
| The maximum diameter of plastic roll | 600mm |
| MAX cutting power | 30 ton |
| Total Weight | 5500KG |
1.This Thermoforming Machine Can use PP transparent Film
2.Change the mold is easy and fast, the forming mold have motor control
3.Use the Servo motor driving the sheet,
4.15 inches Touch screen Control, easy for Operation
5.forming, punching , cutting work independent , could move the distich on the rail .
6.stacking use robot, could stack different size, and depth products.
7.forming, and cutting control by separate servo motor.
